PD3S230L
NEW PROD
UC
T
Maximum Ratings
(@T A = +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage V
RRM
V
RWM
V
R
30 V
Average Forward Current (See also figure 4) I
F(AV)
2.0 A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
I
FSM
30 A
Thermal Characteristics
Characteristic Symbol Typ Max Unit
Thermal Resistance Junction to Soldering Point R θJS
⎯ 6.0 °C/W
Thermal Resistance Junction to Ambient Air (Note 5) T
A
= +25
°C
R θJA 177 ⎯ °C/W
Operating Temperature Range T
J
-65 to +125 °C
Storage Temperature Range T
STG
-65 to +150 °C
Electrical Characteristics
(@T A = +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Reverse Breakdown Voltage (Note 6) V
(BR)R
30 ⎯ ⎯ V I
R
= 1.5mA
Forward Voltage V
F
⎯
⎯ 0.37
0.30 0.45
0.36
V
I
F
= 2.0A, T
A
= +25 °C
I
F
= 2.0A, T
A
= +125 °C
Leakage Current (Note 6) I R
⎯
⎯
40
0.37
250
1.5
μA
mA
V R = 5V, T A = +25
°C
V
R
= 30V, T
A
= +25
°C
Total Capacitance C
T
⎯ 40 ⎯ pF V
R
= 10V, f = 1.0MHz
Notes: 5. FR-4 PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com.
6. Short duration pulse test used to minimize self-heating effect.
