POWERDI is a registered trademark of Diodes Incorporated.
PDS1040CTL
Document number: DS30485 Rev. 13 - 2
2 of 5
February 2014
© Diodes Incorporated
PDS1040CTL
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
40 V
RMS Reverse Voltage
V
R(RMS)
28 V
Average Rectified Output Current (See also Figure 5) per element
total device
I
O
5
10
A
Non-Repetitive Peak Forward Surge Current, per element
8.3ms Single half sine-wave Superimposed on Rated Load
I
FSM
110 A
Thermal Characteristics
Characteristic Symbol
Typ
Max
Unit
Thermal Resistance Junction to Soldering Point
R
θJS
⎯
2.0
°C/W
Thermal Resistance Junction to Ambient Air (Note 5)
R
θJA
95
⎯
°C/W
Thermal Resistance Junction to Ambient Air (Note 6)
R
θJA
75
⎯
°C/W
Thermal Resistance Junction to Ambient Air (Note 7)
R
θJA
50
⎯
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Reverse Breakdown Voltage (Note 8)
V
(BR)R
40
⎯
⎯
V
I
R
= 500µA
Forward Voltage Per Element
V
F
⎯
0.465 0.50
V
I
F
= 5A, T
S
= +25
°C
⎯
0.41 0.45
I
F
= 5A, T
S
= +100
°C
⎯
0.39 0.43
I
F
= 5A, T
S
= +125
°C
⎯
0.55 0.60
I
F
= 10A, T
S
= +25
°C
⎯
0.53 0.57
I
F
= 10A, T
S
= +100
°C
⎯
0.52 0.56
I
F
= 10A, T
S
= +125
°C
Reverse Leakage Current (Note 8) Per Element
I
R
⎯
20 200 µA
V
R
= 40V, T
S
= +25°C
⎯
3 25 mA
V
R
= 40V, T
S
= +100°C
⎯
15 150 µA
V
R
= 35V, T
S
= +25°C
⎯
2.5 10 mA
V
R
= 35V, T
S
= +100°C
⎯
6 80 µA
V
R
= 17.5V, T
S
= +25°C
⎯
1 5 mA
V
R
= 17.5V, T
S
= +100°C
Notes:
5. FR-4 PCB, 2 oz. Copper, minimum recommended pad lay
6. Polyimide PCB, 2 oz. Copper, minimum recommended pad layout per
7. Polyimide PCB, 2 oz. Copper. Cathode pad dimensions 9.4mm x 7.2mm. Anode pad dimensions 2.7mm x 1.6mm.
8. Short duration pulse test used to minimize self-heating effect.
