POWERDI is a registered trademark of Diodes Incorporated.
PDS360
Document number: DS30479 Rev. 11 - 2
2 of 5
October 2012
© Diodes Incorporated
PDS360
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
60 V
RMS Reverse Voltage
V
R(RMS)
42 V
Average Rectified Output Current (See also Figure 4)
I
O
3 A
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave superimposed on rated load
I
FSM
100 A
Thermal Characteristics
Characteristic Symbol
Typ
Max
Unit
Thermal Resistance Junction to Soldering Point
R
θJS
⎯
3.0
°C/W
Thermal Resistance Junction to Ambient Air (Note 5) T
A
= +25°C
R
θJA
95
⎯
°C/W
Thermal Resistance Junction to Ambient Air (Note 6) T
A
= +25°C
R
θJA
70
⎯
°C/W
Thermal Resistance Junction to Ambient Air (Note 7) T
A
= +25°C
R
θJA
50
⎯
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Reverse Breakdown Voltage (Note 8)
V
(BR)R
60
⎯
⎯
V
I
R
= 0.2mA
Forward Voltage
V
F
⎯
0.57 0.62
V
I
F
= 3A, T
J
= +25
°C
⎯
0.53 0.60
I
F
= 3A, T
J
= +100
°C
⎯
0.51 0.57
I
F
= 3A, T
J
= +125
°C
⎯
0.70 0.76
I
F
= 6A, T
J
= +25
°C
⎯
0.62 0.70
I
F
= 6A, T
J
= +100
°C
⎯
0.60 0.66
I
F
= 6A, T
J
= +125
°C
Reverse Leakage Current (Note 8)
I
R
⎯
3 150
μA
T
J
= +25
°C, V
R
= 60V
⎯
⎯
10 mA
T
J
= +100
°C, V
R
= 60V
⎯
1.5 15 mA
T
J
= +125
°C, V
R
= 60V
Notes:
5. FR-4 PCB, 2 oz. Copper, minimum recommended pad lay
8. Short duration pulse test used to minimize self-heating effect.
