• For AIX, press Shift, Tab, U, 3, Esc
Display Data Channel (DDC) hotkey
Display Data Channel is a VESA standard for communication between a monitor and a video
adapter. To input the monitor’s DDC information into the Transmitter’s memory, press:
Shift, Tab, D, Esc
Update the DDC information if you replace the monitor. To do so, repeat the above hotkey
sequence.
Changing the Shift hotkey to Ctrl
You can change the hotkey to Ctrl. Once you do so, replace all the instances of Shift appearing
above to Ctrl.
-To change to Ctrl press:
Shift, Tab, C, Esc
-To change back to Shift press:
Ctrl, Tab, S, Esc
Specifications
System
System cable CAT5/6 cable 2x4x24 AWG Solid Wire
Maximum distance 70m/230ft
Mouse support 2 or 3 or 5 button PS/2, Wheel mouse, Intellimouse Explorer
Operating systems All major operating systems
Screen resolution Up to 1600X1200 @ 75Hz (depending on cable length)
Warranty 3 years
Operating temp. 0ºC to 40ºC/32ºF to 104ºF
Storage temp. -40°C to 70°C/-40ºF to 158ºF
Humidity 80% non condensing relative humidity
Transmitter Receiver
Cables &
Connectors Built-in KVM
System – RJ45 VGA – HDD15F
Keyboard – MiniDin6F
Mouse – MiniDin6F
System – RJ45
Power supply From connected computer External switching power adapter
5V DC 110/240
Dimensions 89 x 46 x 25.3mm / 3.5 x 1.8 x 0.9”
Shipping weight 552g/1.21lb
