178.843, 178.846 User Manual
External Inputs
In addition to the unit’s own VHF microphones, 6.3mm jack inputs are provided to connect
external wired or wireless microphones, which are both governed by the MIC VOLUME control.
If required, the music level can be automatically muted when speaking into a microphone by
switching the VCV on.
Also, twin RCA and 3.5mm jack input are provided for line input sources such as CD player or
ipod. To use these, set the MODE switch on the USB/SD player to “LINE IN”
Adjacent to this twin RCA input is a twin RCA line output carrying the overall main mix.
The AUX is governed by the VOLUME control at the top of the panel.
Internal USB/SD/FM player
Insert a USB memory stick or an SD card with compressed audio media stored on it into the
relevant slot on the rear panel.
If the LCD display reads “LINE IN”, press the MP3/LINE button and check that the LCD display
shows that media is being read from the USB or SD device. If not, press the “>II” button or
try removing and re-inserting the memory device.
Increasing the VOLUME control should result in the media being played through the speaker.
Panel controls are detailed below…
“MODE”
Switches music input between internal USB/SD/FM player and AUX input
Pressing “MODE” for 2 seconds opens Media Player Menus (see below)
“VOL – “
Press and hold to decrease volume
“I<<”
Momentary press for previous track (or station in FM mode)
“VOL +”
Press and hold to increase volume
“>>I”
Momentary press for next track (or station in FM mode)
“RECORD”
In any mode, press to record to USB or SD, press again to stop and save
“>II”
Play/Pause USB or SD track, Auto-scan FM tuner, MUTE AUX input
