BPV-SERIES
100V Outdoor Speakers

User Manual

BP3V

75mm (3”), 60Wmax

White

952.810

Black

952.811

BP4V

100mm (4”), 70Wmax

White

952.812

Black

952.813

BP5V

130mm (5.25”), 90Wmax

White

952.814

Black

952.815

BP6V

165mm (6.5”), 120Wmax

White

952.816

Black

952.817


Introduction

Thank you for choosing the BPV-series outdoor speakers. These weatherproof speakers have been
designed to offer high quality sound for 100V line or low impedance installations. Please read and follow
the instructions in this manual to achieve the best results and avoid damage through misuse.

Installation

The BPV-series speakers are each supplied with a wall-mounting bracket which
allows 90° lateral adjustment. When fixing to a wall or ceiling, use the bracket to
mark out the fixing points and use appropriate fixings for the substrate that the
speaker will be attached to, ensuring that the fixing is strong enough to bear the
weight load.

Once the bracket is fitted, support the speaker in position and attach top and bottom using the supplied
M6 screw caps and adjust to the required angle. Further M6 mounting points are available at the rear of
the speaker, should it be preferred to use different mounting methods (e.g. 129.130 – 129.124UK)
