178.843, 178.846 User Manual
Safety
Prior to connecting mains, ensure that the supply voltage is correct and the mains lead is in
good condition.
Avoid ingress of water or particles into the enclosure.
If the mains or D.C. fuse blows, refer the unit to qualified service personnel
If the VHF microphones are to be unused for a long period of time, remove the batteries and
store for later use.
Placement
Keep the unit out of direct sunlight and away from heat sources.
Place the unit in an upright position during use and storage.
Keep the unit away from moisture or dusty environments.
Cleaning
Use a soft cloth with a neutral detergent to clean the cabinet, panel and controls.
To avoid damage, do not use solvents to clean this equipment.
Specifications QR12PA QR15PA
Power supply
220-240Vac 50/60Hz / external 12Vdc / internal battery
Main driver 30cm (12”) 38cm (15”)
HF unit 2.5cm (1”) titanium compression driver
VHF mic frequencies 174.1MHz + 175.0MHz
Output power 50W + 50W (LF + HF)
Battery life Up to 8 hours
Dimensions 570 x 350 x 310mm 685 x 440 x 380mm
Weight 14.0kg 18.4kg
