4

Battery change with no change in zero

Large heads-up display with wide field of view

Parallax-free performance

Submersible in up to 10m (33 ft) of water

Push-button controls for reticle switching, manual override of

auto brightness, night vision mode, and on/off function
Anti-reflective coatings on lens covers, to maintain covertness

Limited Two-Year Warranty

1.3 SpECIFICATIONS

Magnification

1x

Exit Pupil

20x15 mm

Eye Relief

from 100 to 500 mm

Parallax (at 100 m)

less than 0.5 MOA*

Windage & Elevation Adjustment

Range

±1.5°

Windage Adjustment Accuracy

1 click=1.5 MOA (45 mm at 100 m)

Elevation Adjustment Accuracy

1 click=1.2 MOA (36 mm at 100 m)

Reticle Pattern Configuration

red dot/circle (interchangeable)

Reticle Pattern Size:

- dot

- circle

3.5 MOA (10 cm at 100 m)

20 MOA (60 cm at 100 m)

Reticle Brightness Adjustment

auto/manual (MAX or MIN positions)

Power Supply

3V Lithium Battery (CR2032)

Operating Temp

from -40°C to +50°C

Waterproof

10 m for 1 hour

Mounting System

for Picatinny Rail or

for ACOG 4x32 (Trijicon) riflescope

Dimensions

48x40x47 mm (ver. for Picatinny rail)

48x44x52 mm (ver. for ACOG 4x32)

Weight

65 g

* MOA = Minute of Angle
