3 Operating Your H-Series Camera
3–1
Camera Features and Controls
Power
2
×
zoom
White hot/
Display
Black hot
Adjustable
Diopter
Eyepiece
Lens cap
Capture
Brightness
SD Card
door
Battery
door
Hot Shoe/
Tripod mount
Hot Shoe
power contacts
19 mm only
