3—Operating Your Scout Camera Scout Operator’s Manual
20 June 2011
3–7 SD Card Door
The SD Card door is located on the
bottom of the camera in front of the
battery compartment. The SD card,
the USB connector, and the Auto-
Standby Enable switch are located
under the door. See “Auto-Standby
Operation” on page 22.
Note
To open the SD Card door, grasp the
two edges with your thumb and finger
and pull straight up.
Caution!
To close the SD Card door, slide the
lanyard strap back into the camera,
position the door in place, and then
firmly press in the middle of the door
until it is fully seated.
The Hot Shoe must be removed to access the SD Card door.
Do not stretch or break the rubber
lanyard that keeps the door captive
to the camera when opened.
SD Card
door
Lanyard USB
Auto-Standby Enable
switch
SD Card
Grasp SD Card door
edges and pull
