4—Technical Data
Scout Bi-Ocular Operator’s Manual
30
March 2012
4–4
Physical
4–5
Additional Features
4–6
Field of View
Weight (without lens)
2.20 lb. (1 kg) with batteries
Size (L
×
W
×
H)
11.0”
Ч
6.5”
Ч
2.63” (28
Ч
16.5
Ч
6.7 cm)
Still Image Storage,
Format
SD, SDHC card,
JPEG
Video Storage,
Format
SD, SDHC card,
AVI
QD35
Field of View (FoV) BTS-X Pro
13°
×
10°
FoV BTS-XR Pro
18°
×
13°
Minimum Focus Distance
3 meters
QD65
FoV BTS-X Pro
7°
×
5°
FoV BTS-XR Pro
10°
×
8°
Minimum Focus Distance
3 meters
QD100
FoV BTS-X Pro
5°
×
3°
FoV BTS-XR Pro
6°
×
4°
Minimum Focus Distance
4 meters
