Scout Bi-Ocular Operator’s Manual 2—Getting Started
431-BTS0-00-10, Revision 110 7
2–2 Lens Options
The QD35, QD65, and QD100 manual focus lenses (as selected at
purchase) include a lens cap, rear lens cover, and lens cloth. Each lens
has a dedicated storage location in the Hard Carrying Case, or the
case can be adjusted to store the lens while still attached to the
camera.
Refer to “Field of View” on page 30 for field of view details and
minimum focus distance; and “Range Detection” on page 31 for a
comparative description of camera performance using the different
lens options with the two different models, BTS-X Pro and BTS-XR Pro.
QD65 QD35 QD100
100 mm Lens 65 mm Lens 35 mm Lens
Manual Focus Ring
