1. DESCRIPTION AND DATA

DESCRIPTION

If low-cost, high quality head-mounted night vision is what you need, the Armasight Vega is the best

choice for you! The Generation 1 Vega comes complete with a head mount that allows the unit to be

positioned over either eye, and is the perfect inexpensive, hands-free option for air soft games, paint-

ball, hunting or security at night, where the Armasight Vega will give you the edge. A built-in, short-

range IR illuminator allows the Vega to work exceptionally well even in complete darkness, and an

optional Armasight long-range infrared illuminator will dramatically boost your viewing range when

required. The Armasight Vega features all-glass optics, a single, push-button control, and durable, re-

inforced composite housing.

FEATURES

compact and lightweight

–

designed for hand-free operations

–

high resolution gen. 1+ image intensifier tube

–

Built-in flood infrared illuminator

–

fully adjustable headgear for ultimate comfort

–

flip-up headgear

–

special design which allows the unit to be positioned over either eye

–

can be used in conjunction with long-range ir illuminator

–

Water and fog resistant

–

limited two-year Warranty

–

SPECIFICATIONS

Generation

Magnification

Objective lens diameter (mm)

20.6

Lens system

35 mm; F/1.7

Field of view (°)

Focus range (m)

0.2 to infinity

Exit pupil diameter (mm)

Eye relief (mm)

Power Supply

CR-123 Lithium (1) 3V

Battery life IR On (hour)

up to 12

Battery life IR Off (hour)

up to 58

Body material

Glass-fiber reinforced composite

Lens material/type

Multicoated heavy glass

Operating temperature (°C)

-30 to +45

Dimensions (LxWxH, mm/in)

147 x 82 x 46 / 5.8 x 3.2 x 1.8

Weight (kg/lbs)

0.25 / 0.54
