5
WARNING :
take into consideration the following information and restrictions in order to avoid damag-
ing the device and to ensure a long service life and failure-free operation:
• Performance of the device in nighttime conditions depends on the level of ambient light in
the environment. Some light (moonlight, starlight, etc.) is required for the device to provide an
image.
• Ambient light level is reduced by the presence of clouds, shade, or objects that block natural
light (buildings, trees, etc.).
• The device loses its effectiveness when operated in shadowed areas.
• The effectiveness of the device is adversely affected by weather conditions such as rain,
snow, sleet, or fog, and environmental conditions such as smoke or dust.
• The device resolution level is reduced in environments with very low light sources. The vis-
ibility will degrade significantly under starlit conditions, particularly in low contrast environ-
ments such as deserts, large areas of uniform vegetation, etc.
• The device is equipped with a protection system that will automatically disable the image
intensifier tube when the illuminance level stays above 40 lux for over 10 seconds.
BATTERY INSTALLATION
1) Unscrew the battery compartment cap on the back side of the goggles body.
2) Insert the CR123A battery into the battery compartment in accordance with polarity markings.
3) Screw the cap onto the place.
ATTACHING THE NINOx TO A HEAD MOUNT
To attach your Ninox to a head mount perform the following steps:
1) Loosen the screw (A), press the button (B); put the binocu-
lar rail into the headset socket (C).
2) Put the head mount, with the Ninox attached, on your
head.
3) Loosen the screw (A) and perform an eye relief adjustment
by moving the binocular on the rail.
4) The head mount intended for use with the Ninox is fitted
with a flip-up mechanism. Press the button (D) from the head
mount side and lift the binocular to the top position.
5) To return the unit back to the operating position, press the
button (D) again and lower the binocular.
6) Press the button (E) and move the binocular on the rail (F)
to reach the most comfortable position for observation.
3. OPERATION INSTRUCTIONS
CONTROLS
The Ninox is designed to meet the needs and requirements of various users. Each user can individually
set the unit to the most desirable and effective position with the help of the controls. The Ninox unit
controls and indicators are shown and detailed further, below:
on/off Button. Press the button to turn the unit on. Press the button again to turn the unit off. The IR
will also turn off automatically.
C
A
B
D
E
F
