1. DESCRIPTION AND DATA
DESCRIPTION
If low-cost, high quality head-mounted night vision is what you need, the Armasight Ninox is the best
choice for you! The Generation 1 Ninox comes complete with a flip-up head mount and is the perfect
inexpensive, hands-free option for air soft games, paintball, hunting or security at night, where the Ar-
masight Ninox will give you the edge. A built-in, short-range IR illuminator with pivotal flood lens allows
the Ninox to work exceptionally well even in complete darkness, and an optional Armasight long-range
infrared illuminator will dramatically boost your viewing range when required. The Armasight Ninox
features all-glass optics, a simple, push-button control, and durable, reinforced composite housing.
FEATURES
compact and lightweight
–
designed for hand-free operations
–
high resolution gen. 1+ image intensifier tube
–
Built-in ir illuminator with pivotal lens to select between ir spot and flood beam
–
fully adjustable headgear for ultimate comfort
–
flip-up headgear
–
dual-eye viewing system for comfortable nighttime operation, even during long sessions
–
can be used in conjunction with long-range ir illuminator
–
water and fog resistant
–
limited two-year warranty
–
SPECIFICATIONS *
Generation 1+
Magnification 1x
Objective lens diameter (mm) 20.6
Lens system 35 mm; F/1.7
Field of view (°) 40
Focus range (m) 0.2 to infinity
Exit pupil diameter (mm) 8
Eye relief (mm) 20
Power Supply CR-123 Lithium (1) 3V
Battery life IR On (hour) up to 12
Battery life IR Off (hour) up to 58
Body material Glass-fiber reinforced composite
Lens material/type Multicoated heavy glass
Operating temperature (°C) -30 to +45
Dimensions (LxWxH, mm/in) 189 x 140 x 63 / 7.4 x 5.5 x 2.5
Weight (kg/lbs) 0.65 / 1.4
* Armasight© reserves the right to modify these specifications at any time without notice.
