OPERATING INSTRUCTIONS
3.1 INSTALLATION AND MOUNTING
CAUTION
:
To protect the intensifier tube when the sight is not in use or when it is being operated in day-
light, keep the protective lens cap securely fitted over the lens.
3.1.1 BATTERY INSTALLATION
The Nyx7-4.5x PRO operates on a single CR123A or AA battery.
Depending on the size of the battery used, it may be necessary to reposition the battery adapter
within the battery cap.
NOTE
:
If operating the device at temperatures below -20°C (-4°F), the use of an alkaline battery is not
recommended, as the severe cold will adversely affect the life of the battery. In these conditions,
it is recommended that you use a lithium-iron disulfide 1.5V AA battery, or its equivalent.
Install the CR123A battery as follows:
FIGURE 3-1. BATTERY INSTALLATION
B
C
A
C
D
A
