Menu Navigation:
The four (4) pushbuttons located on the front of the transmitter operate the micro-processor:
¾ green ENTER (select)
¾ yellow UP ARROW
¾ yellow DOWN ARROW
¾ blue MENU (escape)
Main Menu:
Access the MAIN MENU by pressing the MENU key:
MAIN MENU
AUTO SAMPLE
MANUAL SAMPLE
CALIBRATE
24.5 C 100 KPA
Range Selection:
The GPR-1500/1500D transmitter is equipped with five (5) standard measuring ranges (see specification) and provides users
with a choice of sampling modes. By accessing the MAIN MENU, users may select either the AUTO SAMPLING (ranging) or
MANUAL SAMPLING (to lock on a single range) mode.
Note: For calibration purposes, use of the AUTO SAMPLE mode is recommended. However, the user can select the full scale
MANUAL SAMPLE RANGE for calibration as dictated by the accuracy of the analysis required – for example, a span gas with an
80 ppm oxygen concentration with the balance nitrogen would dictate the use of the 0-100 ppm full scale range for calibration
and a 0-10 ppm measuring range.
Procedure - Auto Sampling:
1. Access the MAIN MENU by pressing the MENU key.
2. Advance the reverse shade cursor using the ARROW keys to highlight AUTO SAMPLE.
3. Press the ENTER key to select the highlighted menu option.
4. The display returns to the sampling mode:
MAIN MENU
AUTO SAMPLE
MANUAL SAMPLE
CALIBRATE
24.5 C 100 KPA
3.3 PPM
AUTO SAMPLING
10 PPM RANGE
24.5 C 100 KPA
5. The display will shift to the next higher range when the oxygen reading (actually the sensor’s signal output) exceeds 99.9%
of the upper limit of the current range. The display will shift to the next lower range when the oxygen reading drops to
85% of the upper limit of the next lower range.
6. For example, if the transmitter is reading 1% on the 0-10% range and an upset occurs, the display will shift to the 0-25%
range when the oxygen reading exceeds 9.9%. Conversely, once the upset condition is corrected, the display will shift back
to the 0-10% range when the oxygen reading drops to 8.5%.
Procedure - Manual Sampling:
Access the MAIN MENU by pressing the MENU key.
Advance the reverse shade cursor using the ARROW keys to highlight MANUAL SAMPLE.
Press the ENTER key to select the highlighted menu option.
The following displays appear:
