HRT 8300 ENG 9
Engl
ish
Control Elements
1)
Go to next channel (CH+)
2) On/off (Standby, equivalent to the POWER-button on the remote control)
3) Go to previous channel (CH-)
4) Receiver of the remote control signal (IR)
5) LED-display (yellow): displays the program number if the receiver is on.
6) USB 2.0 port
A) Antenna
input
B) Antenna output
C) SCART (output)
D) HDMI (output)
E) Analoge Video output (CVBS / YPbPr)
F) Audio output (analog R/L, digital S/PDIF, coaxial)
G) Power cord
Front side
Rear side
1 2 3 5 4 6
A C D E B F G
