ASUS H61M-D 1-3
1.2.4 Layout contents
Connectors/Jumpers/Slots/LED Page
1. PS2 and USB device wakeup (PS2_USBPW1~4) 1-11
2. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V) 1-14
3. CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN) 1-16
4. Intel ® LGA1155 CPU socket 1-3
5. DDR3 DIMM slots 1-7
6. Speaker connector (4-pin SPEAKER) 1-14
7. System panel connector (10-1 pin F_PANEL) 1-17
8. Intel ® H61 Serial ATA 3.0Gb/s connector (7-pin SATA3G_1~4) 1-15
9. Clear RTC RAM (3-pin CLRTC) 1-10
10. USB 2.0 connectors (10-1 pin USB56, USB78, USB910) 1-16
11. USB device wake-up (USBPW5~10) 1-12
12. Front panel audio connector (10-1 pin AAFP) 1-15
13. Onboard LED (SB_PWR) 1-17
1.3 Central Processing Unit (CPU)
This motherboard comes with a surface mount LGA1155 socket designed for the Intel ®
3rd/2nd generation Core™ i7 / Core™ i5 / Core™ i3, Pentium ® , Celeron ® processors.
H61M-D
H61M-D CPU socket LGA1155
