ASUS P4PE motherboard user guide 2-25
11. USB header (10-1 pin USB_56)
If the USB ports on the rear panel are inadequate, a USB header is
available for additional USB ports. The USB header complies with USB
2.0 specification that supports up to 480 Mbps connection speed. This
speed advantage over the conventional 12 Mbps on USB 1.1 allows
faster Internet connection, interactive gaming, and simultaneous
running of high-speed peripherals.
If your package came with a USB 2.0/GAME module, connect the USB
cable to this header. The module has two USB 2.0 ports that support
the next generation USB peripherals such as high resolution cameras,
scanners, and printers.
You must install the driver before you can use the USB 2.0 capability.
P4PE
®
P4PE USB 2.0 Header
USB_56
USB+5V LP5- LP5+ GND NC
USB+5V
LP4- LP4+ GND
1
NEVER connect a 1394 cable to the USB_56 connector. Doing so will
damage the motherboard!
