xi
M3A78 specifications summary
ASUS special features ASUS Express Gate:
- Access the Internet in 5-second* boot time without
entering Windows
- A built-in OS offers instant fun platform for Internet
and Instant Messenger
- User-friendly Picture Manager Interface
* The actual boot time is subject to hardware
configurations and product models.
ASUS AI NET2
ASUS Q-Fan
ASUS CrashFree BIOS3
ASUS EZ Flash2
ASUS MyLogo2
Back panel I/O ports 1 x PS/2 Keyboard port
1 x Optical S/PDIF Out port
1 x COM port
1 x LPT port
1 x RJ45 port
6 x USB 2.0/1.1 ports
8-channel Audio I/O ports
BIOS 8Mb Flash ROM, AMI BIOS, PnP, DMI2.0, WfM2.0,
ACPI2.0a, SMBIOS 2.5
ASUS overclocking
features
SFS (Stepless Frequency Selection) from 200MHz to
300MHz at 1MHz increment
Adjustable CPU voltage at 0.025V increment
ASUS CPR (CPU Parameter Recall)
Internal I/O connectors 3 x USB 2.0 connectors support additional 6 USB 2.0/1.1
ports
1 x Floppy disk drive connector
1 x IDE connector
6 x SATA connectors
High definition front panel audio connector
1 x system panel connector
1 x CD audio-in connector
1 x S/PDIF Out header
1 x Chassis intrusion connector
Power/CPU/Chassis Fan connectors
24-pin EATX power connector
4-pin ATX 12V power connector
(continued on the next page)
