ASUS P5KPL/1600 1-9
1.5.4 Layout contents
Slots Page
1. DDR2 DIMM slots 1-17
2. PCI slots 1-24
3. PCI Express x 16 slot 1-24
Jumpers Page
1. Clear RTC RAM (3-pin CLRTC) 1-25
Rear panel connectors Page
1. PS/2 mouse port (green) 1-26
2. Parallel port 1-26
3. LAN (RJ-45) port 1-26
4. Rear speaker out port (black) 1-26
5. Center/Subwoofer port (orange) 1-26
6. Line in port (light blue) 1-26
7. Line out port (lime) 1-26
8. Microphone port (pink) 1-26
9. Side speaker out port (gray) 1-27
10. USB 2.0 ports 1 and 2 1-27
11. USB 2.0 ports 3 and 4 1-27
12. Serial port 1-27
13. Optical S/PDIF Output 1-27
14. PS/2 keyboard port (purple) 1-27
Internal connectors Page
1. Floppy disk drive connector (34-1 pin FLOPPY) 1-28
2. Optical drive audio in connector (4-pin CD) 1-28
3. IDE connector (40-1 pin PRI_IDE) 1-29
4. Serial ATA connectors (7-pin SATA1, SATA2, SATA3, SATA4) 1-29
5. Digital audio connector (4-1 pin SPDIF_OUT) 1-30
6. Front panel audio connector (10-1 pin AAFP) 1-31
7. USB connectors (10-1pin USB56, USB78) 1-31
8. CPU, chassis, and power fan connectors (4-pin CPU_FAN, 3-pin
CHA_FAN, and 3-pin PWR_FAN) 1-32
9. Chassis intrusion connector (4-1 pin CHASSIS) 1-32
10. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V) 1-33
11. System panel connector (20-8 pin F_PANEL) 1-34
