ASUS M4A78L-M

2-17

2.5.5

HW Monitor Configuration

CPU Temperature [xxxºC/xxxºF] or [Ignored]

MB Temperature [xxxºC/xxxºF] or [Ignored]

The onboard hardware monitor automatically detects and displays the motherboard and CPU

temperatures. Select Ignored if you do not wish to display the detected temperatures.

CPU Fan Speed [N/A], [xxxxRPM], or [Ignored]

The onboard hardware monitor automatically detects and displays the CPU fan speeds in

rotations per minute (RPM). If the fan is not connected to the motherboard, the field shows

N/A. Select [gnored] if you do not want the detected speed to be displayed.

CPU Q-Fan Control [Disabled]

Enables or disables the ASUS Q-Fan feature that smartly adjusts the CPU fan speeds for

more efficient system operation. Configuration options: [Disabled] [Enabled]

Chassis Fan Speed [N/A], [xxxxRPM], or [Ignored]

The onboard hardware monitor automatically detects and displays the Chassis fan speeds in

rotations per minute (RPM). If the fan is not connected to the motherboard, the field shows

N/A. Select [gnored] if you do not want the detected speed to be displayed.

VCORE Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage [xx.xxxV] or [Ignored]

The onboard hardware monitor automatically detects the voltage output through the onboard

voltage regulators.

2.5.6

Anti Surge Support [Enabled]

Enables or disables the Anti Surge feature. Configuration options: [Enabled] [Disabled]

Power on From S5 By RTC Alarm [Disabled]

Enables or disables RTC to generate a wake event. Configuration options: [Disabled]

[Enabled]

2.6

Boot menu

The Boot menu items allow you to change the system boot options. Select an item then

press to display the submenu.

Select Screen

Select Item

Enter Go to Sub Screen

F1 General Help

F10 Save and Exit

ESC Exit

v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.

Boot Settings Configuration

Security

Specifies the Boot

Device Priority

sequence.

A virtual floppy disk

drive (Floppy Drive B:)

may appear when you set

the CD-ROM drive as the

first boot device.

BIOS SETUP UTILITY

Main Advanced Power

Boot

Tools Exit

Boot Device Priority

Boot Settings
