ASUS H87I-PLUS 2-15
Target CPU Graphics Speed : xxxxMHz
Displays the target CPU Graphics speed.
2.5.1 Ai Overclock Tuner [Auto]
Allows you to select the CPU overclocking options to achieve the desired CPU internal
frequency. Select any of these preset overclocking configuration options:
[Auto]
Loads the optimal settings for the system.
[Manual] Allows you to automatically optimize the CPU ratio and BCLK frequency.
[X.M.P.] Allows your system to automatically optimize the CPU ratio, BCLK
frequency, and memory parameters. If you install memory modules
supporting the eXtreme Memory Profile (X.M.P.) Technology, select this
item to set the profiles supported by your memory modules for optimizing
the system performance.
2.5.2 ASUS MultiCore Enhancement [Enabled]
[Enabled] Default set to [Enabled] for maximum performance under XMP/Manual/
User-defined memory frequency mode.
[Disabled] Allows you to set to default core ratio settings.
2.5.3 CPU Core Ratio [Auto]
Allows you to set the CPU ratio and sync automatically, per core or all cores. Configuration
options: [Auto] [Sync All Cores] [Per Core]
When the CPU Core Ratio is set to [Per Core] or [Sync All Cores], the following items
appear:
1-Core Ratio Limit [Auto]
Allows you to set the 1-Core Ratio Limit. Select [Auto] to apply the CPU default Turbo Ratio
setting or manually assign a 1-Core Ratio Limit value that is higher than or equal to the 2-
Core Ratio Limit.
2-Core Ratio Limit [Auto]
This item becomes configurable only when the CPU Core Ratio is set to [Per Core] and
allows you to set the 2-Core Ratio Limit. Select [Auto] to apply the CPU default Turbo Ratio
setting or manually assign a 2-Core Ratio Limit value that is higher than or equal to the 3-
Core Ratio Limit. 1-Core Limit must not be set to [Auto].
3-Core Ratio Limit [Auto]
This item becomes configurable only when the CPU Core Ratio is set to [Per Core] and
allows you to set the 3-Core Ratio Limit. Select [Auto] to apply the CPU default Turbo Ratio
setting or manually assign a 3-Core Ratio Limit value that is higher than or equal to the 4-
Core Ratio Limit. 1-Core/2-Core Ratio Limit must not be set to [Auto].
