12
ASUS Wi-Fi GO! card specifications
Bluetooth v4.0/3.0 + HS Wi-Fi 802.11 a/b/g/n version
Wi-Fi Standard IEEE 802.11 a/b/g/n
Bluetooth standard Bluetooth v4.0/3.0 + HS
Data rate
802.11n(HT40*) up to 300Mbps
802.11n(HT20) up to 150Mbps
802.11a up to 54Mbps
802.11b up to 11Mbps
802.11g up to 54Mbps
* When using Wi-Fi Engine in AP mode, the channel bandwidth is limited
to HT20 and with a maximum data rate of 150 Mbps due to Windows ®
limitation.
Security
WEP, WPA & WPA2*
* Use WPA2 or open system to reach 65Mbps and above.
Network architechture
types
AP Mode
Client mode
Frequency band 2.4GHz & 5GHz ISM radio band
Operating range
Wi-Fi:*
Outdoor up to 300 meters
Indoor up to 100 meters
* The transmission speed may vary according to the environment
Bluetooth:
10 - 20 meters (depends on the environment)
Antenna
Antenna 1: Wi-Fi Tx/Rx
Antenna 2: Wi-Fi Tx/Rx + Bluetooth
1 x ASUS 2T2R dual band Wi-Fi moving antenna (with SMA
connector)
LED
Wi-Fi:
Green LED: Wi-Fi enabled
LED off: Wi-Fi disabled
Bluetooth:
Blue LED: Bluetooth enabled
LED off: Bluetooth disabled
Blinking blue LED: Data activity
Support OS 32-bit / 64-bit Windows ® 7, 32-bit / 64-bit Windows ® 8
ASUS special features
ASUS Wi-Fi Engine
ASUS Wi-Fi GO!
* The specifications are subject to change without notice.
The Wi-Fi GO! card varies by models. Refer to your motherboard manual for the Wi-Fi GO!
card specification.
