Installation
Follow the steps below to install the PoE Splitter:
1. Before installing the PoE Splitter, make sure that all devices are cut from
power supply.
2.Connect the Data In port on the PoE Splitter with the Data out port on
your PoE Switch or Hub. If your Switch or Hub does not support PoE
function, you need to install a PoE injector between your Switch/HUB and
PoE Splitter.
3. Use an Ethernet cable to connect the Data out port on the PoE Splitter to
the RJ-45 port on your PD (Such as Router, Access Point...etc.)
4. Choose the power cable that goes with your PD power port.
5. Use the power cable to connect the PoE Splitter Power Out jack with the
PDʼs power jack.
6. Adjust the Voltage according to the specification of your PD. The PoE
Splitter supports four type of voltage – 5V, 7.5V, 9V and 12V. The default
value is set to 5V. Before you adjust the voltage, make sure the PoE
Splitter is powered off.
