5-25 ASUS T-Series M3N8200
5.4.4 Onboard Devices Configuration
On Board Devices Configuration
AZALIA Audio [Enabled]
Front Panel Select [HD Audio]
Onboard LAN [Enabled]
Onboard LAN BootROM [Disabled]
VIA VT6308P Firewire 1394 [Enabled]
Serial Port1 Address [3F8/IRQ4]
Serial Port1 Address [3F8/IRQ4]
Serial Port1 Mode [Normal]
AZALIA Audio [Enabled]
Enables or disables the Azalia/AC’97 CODEC.
Configuration options: [Enabled] [Disabled]
Front Panel Select [Enabled]
Allows you to select AC97 mode or HD Audio mode.
Configuration options: [AC97] [HD Audio]
Onboard LAN [Enabled]
Enables or disables the onboard LAN controller.
Configuration options: [Enabled] [Disabled]
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Onboard LAN A Boot ROM [Disabled]
Allows you to enable or disable the option ROM in the onboard LAN A
controller. Configuration options: [Disabled] [Enabled]
VIA VT6308P Firewire 1394 [Enabled]
Enables or disables the onboard VIA VT6308P Firewire 1394.
Configuration options: [Enabled] [Disabled]
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [2F8/IRQ4] [3E8/IRQ4] [2F8/IRQ3]
Serial Port2 Mode [Normal]
Allows you to set the BIOS selection mode for Serial Port2.Configuration
options: [Normal] [IrDA] [ASK IR]
Enable or disable
High Definition Audio
Controller
