ASUS ESC1000 G2 6-13
5. After the system has restarted,
a message appears indicating
that the auto-tuning process is
successful. Click OK to exit.
6.3.3 DIGI+ Power Control
DIGI+ Power Control allows you to adjust VRM voltage and frequency modulation to enhance
reliability and stability. It also provides the highest power efficiency, generating less heat to
prolong the component lifespan and minimize power loss.
To launch DIGI+ Power Control, click Tool > DIGI+ Power Control on the AI Suite II main
menu bar.
Application help
1
CPU Power
2
3
6
7
4 5
Applies all the
changes immediately
Undoes all the
changes
Function no. Function description
1 CPU Load-line Calibration
It allows you to adjust the voltage settings and control the system
temperature. Higher load-line calibration could get higher voltage and good
overclocking performance but increases the CPU and VRM thermal.
2 CPU Current Capability
CPU Current Capability provides wider total power range for overclocking.
A higher value setting gets higher VRM power consumption delivery.
3 CPU Voltage Frequency
Switching frequency will affect the VRM transient response and component
thermal. Higher frequency gets quicker transient response.
4 VCCSA Load-line Calibration
The behavior of the DRAM Controller is decided by the VCCSA Load-line.
Set to a higher value for system performance, or to a lower value for better
thermal solution.
