F1A55 R2.0 specifications summary
CPU AMD ® Fusion™ A- & E2 series accelerated processors, up to 4 CPU cores,
FM1 socket
AMD ® Turbo Core Technology 2.0 support
• The AMD ® Turbo Core technology 2.0 support depends on the APU types.
• Refer to www.asus.com for the AMD ® CPU support list.
Chipset AMD ® A55 FCH (Hudson D2)
Memory 4 x DDR3 DIMMs, max. 64GB, DDR3 2250(O.C.) / 1866 / 1600 / 1333 /
1066 MHz, non-ECC, un-buffered memory
Dual-channel memory architecture
• The maximum 64GB memory capacity can be supported with 16GB or above
DIMMs. ASUS will update the memory QVL once the DIMMs are available in the
market.
• Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List).
• When you install a total memory of 4GB capacity or more, Windows® 32-bit
operating system may only recognize less than 3GB. We recommend a
maximum of 3GB system memory if you are using a Windows® 32-bit operating
system.
Graphics Integrated AMD ® Radeon™ HD 6000 series graphics in the Llano APU
Supports AMD ® Dual Graphics
• Refer to www.amd.com for the discrete GPUs that support AMD ® Dual Graphics.
Expansion slots 2 x PCI Express 2.0 x16 slot (blue @x16 mode, black @x4 mode)
2 x PCI Express 2.0 x1 slots
3 x PCI slot
Multi-GPU support Supports AMD ® CrossFireX™ technology
Storage / RAID AMD ® A55 FCH
- 6 x Serial ATA 3.0 Gb/s connectors support RAID 0, RAID 1, RAID 10
and JBOD configurations
LAN
Realtek® RTL8111E Gigabit LAN Controller
Audio ALC887 8-channel High Definition Audio CODEC
- Supports Jack-Detection, Multi-Streaming, and Front Panel Jack-
Retasking
- Supports S/PDIF out interface at the back I/O
USB AMD® A55 FCH:
- 12 x USB 2.0/1.1 ports (6 ports at the mid-board, 6 ports at the back
panel)
Asmedia® USB 3.0 controller:
- 2 x USB 3.0 ports (blue, at the back panel)
