Asus P5AD2-E Premium - Manual (Page 51)

A S U S P 5 A D 2 - E P r e m i u m A S U S P 5 A D 2 - E P r e m i u m A S U S P 5 A D 2 - E P r e m i u m A S U S P 5 A D 2 - E P r e m i u m A S U S P 5 A D 2 - E P r e m i u m 2 - 2 9 2 - 2 9 2 - 2 9 2 - 2 9 2 - 2 9
7 . 7 . 7 . 7 . 7 . O p t i c a l d r i v e a u d i o c o n n e c t o r ( 4 - p i n C D ) O p t i c a l d r i v e a u d i o c o n n e c t o r ( 4 - p i n C D ) O p t i c a l d r i v e a u d i o c o n n e c t o r ( 4 - p i n C D ) O p t i c a l d r i v e a u d i o c o n n e c t o r ( 4 - p i n C D ) O p t i c a l d r i v e a u d i o c o n n e c t o r ( 4 - p i n C D )
This connector is for the 4-pin audio cable that connects to the audio
connector at the back of the optical drive.
Enable the CD-IN function in the audio utility when using this
connector.
6 . 6 . 6 . 6 . 6 . D i g i t a l a u d i o c o n n e c t o r ( 6 - 1 p i n S P D I F ) D i g i t a l a u d i o c o n n e c t o r ( 6 - 1 p i n S P D I F ) D i g i t a l a u d i o c o n n e c t o r ( 6 - 1 p i n S P D I F ) D i g i t a l a u d i o c o n n e c t o r ( 6 - 1 p i n S P D I F ) D i g i t a l a u d i o c o n n e c t o r ( 6 - 1 p i n S P D I F )
This connector is for an additional Sony/Philips Digital Interface
(S/PDIF) port(s). Connect the S/PDIF module cable to this connector,
then install the module to a slot opening at the back of the system
chassis.
The S/PDIF module is purchased separately.
P5AD2-E PREMIUM
®
P5AD2-E PREMIUM Digital audio connector
SPDIF
GND
+5V
SPDIF_IN
SPDIF_OUT
GND
1
P5AD2-E PREMIUM
®
P5AD2-E PREMIUM CD audio connector
CD
Right A
udio Channel
Left A
udio Channel
Ground Ground
