ix
(continued on the next page)
P8H77-V specifications summary
CPU LGA1155 socket for Intel ® 3rd/2nd Generation Core™ i7 / Core™ i5 / Core™ i5 /
Core™ i3 / Pentium ® / Celeron ® Processors Processors
Supports 22/32nm CPU
Supports Intel
® Turbo Boost Technology 2.0
• The Intel ® Turbo Boost Technology 2.0 support depends on the CPU
types.
• Refer to Refer to www.asus.com for Intel CPU support list.
Chipset Intel ® H77 Express Chipset
Memory 4 x DIMMs, max. 32GB, DDR3 2200(O.C.)/2133(O.C.)/2000(O.C.)/
1866(O.C.)/1600/1333/1066 MHz, non-ECC, un-buffered memory
Dual channel memory architecture
Supports Intel
® Extreme Memory Profile (XMP)
• DDR3 1600 MHz and higher memory fre�uency is supported by Intel DDR3 1600 MHz and higher memory fre�uency is supported by Intel ®
3rd generation processors.
• Due to the CPU behavior�� DDR3 2133/1866 MHz memory module will Due to the CPU behavior�� DDR3 2133/1866 MHz memory module will
run at DDR3 2000/1800 MHz fre�uency as default.
• Refer to Refer to www.asus.com for the latest Memory QVL (Qualified
Vendors List).
• When you install a total memory of 4GB capacity or more�� Windows When you install a total memory of 4GB capacity or more�� Windows ®
32-bit operating system may only recognize less than 3GB. We
recommend a maximum of 3GB system memory if you are using a
Windows ® 32-bit operating system.
Expansion slots 1 x PCI Express 3.0* x16 slot [blue] (at x16 mode)
1 x PCI Express 2.0 x16 slots [black] (at x4 mode, compatible with PCIe x1
and x4 devices)
2 x PCI Express 2.0 x1 slots
3 x PCI slots
• PCIe 3.0 speed is supported by Intel PCIe 3.0 speed is supported by Intel ® 3rd generation Core™
processors.
VGA
Integrated graphics processor - Intel ® HD Graphics support
Multi-VGA output support: HDMI, DisplayPort, DVI-D, RGB ports
Supports HDMI with max. resolution of 1920 x 1200 @60Hz
Supports DisplayPort 1.1a with max. resolution of 2560 x 1600 @60Hz
Supports DVI with max. resolution of 1920 x 1200 @60Hz
Supports RGB with max. resolution of 2048 x 1536 @75Hz
Supports Intel
® InTru™ 3D/Quick Sync Video/Clear Video HD Technology/
Insider™
Maximum shared memory of 1696 MB
Multi-GPU support Supports ATI ® Quad-GPU CrossFireX™ Technology
Supports Lucidlogix ® Virtu MVP™ Technology*
• LucidLogix LucidLogix ® Virtu MVP™ supports Windows ® 7 operating systems.
LAN Qualcomm Atheros ® 8161 PCIe Gigabit LAN controller
