2-14 Chapter 2: Getting started
2.4.6 CPU Power Management
The sub-items in this menu allow you to set the CPU ratio and features.
CPU Ratio [Auto]
Allows you to manually adjust the maximum non-turbo CPU ratio. Use <+> and <-> keys to
adjust the value. The valid value ranges vary according to your CPU model.
Enhanced Intel SpeedStep Technology [Enabled]
Allows you to enable or disable the Enhanced Intel ® SpeedStep Technology (EIST).
[Disabled] Disables this function.
[Enabled] The operating system dynamically adjusts the processor voltage and
core frequency which may result in decreased average consumption and
decreased average heat production.
Turbo Mode [Enabled]
This item appears only when you set the previous item to [Enabled].
[Enabled]
Allows processor cores to run faster than marked frequency in specific
conditions.
[Disabled] Disables this function.
The following three items appear only when you set both the Enhanced Intel SpeedStep
Technology and Turbo Mode items to [Enabled].
Long Duration Power Limit [Auto]
Allows you to limit the turbo ratio’s long duration power. Use the <+> and <-> keys to
adjust the value.
Long Duration Maintained [Auto]
Allows you to maintain the turbo ratio’s long duration power. Use the <+> and <-> keys
Use the <+> and <-> keys
to adjust the value.
Short Duration Power Limit [Auto]
Allows you to limit the turbo ratio’s long duration power. Use the <+> and <-> keys to
Use the <+> and <-> keys to
adjust the value.
Primary Plane Current Limit [Auto]
Maximum instantaneous current allowed at any given time for CPU cores. Use <+>
Use <+>
and <-> key to adjust the value at 0.125A increment. . .
Secondary Plane Current Limit [Auto]
Maximum instantaneous current allowed at any given time for Internal Graphics cores.
Use <+> and <-> key to adjust the value at 0.125A increment.
