ASUS M4A77TD 2-11
Overclock Options [Auto]
Selects the overclocking profile. Configuration options: [Auto] [Overclock 2%]
[Overclock 5%] [Overclock 8%] [Overclock 10%]
CPU Ratio [Auto]
Sets the ratio between the CPU Core Clock and the CPU Bus Frequency. Use the <+> / <->
keys to adjust the ratio. The valid value ranges vary depending on your CPU model.
CPU Over Voltage [Auto]
Sets the CPU over voltage. The valid value ranges vary depending on your CPU model. Use
<+> / <-> keys to adjust the ratio. Configuration options: [Auto]
VDDNB Over Voltage [Auto]
Sets the VDDNB over voltage. The valid value ranges vary depending on your CPU model.
Use <+> / <-> keys to adjust the ratio. Configuration options: [Auto]
LoadLine Calibration [Auto]
Sets LoadLine. The values range from 0% to 100% with a 3.225% increment. Use the <+> /
<-> keys to adjust the value. Configuration options: [Auto] [Max. = 100%] [Min. = 0%]
HT Link Speed [Auto]
Sets the HyperTransport link speed. Configuration options: [200MHz] [400MHz] [600MHz]
[800MHZ] [1000MHz] [1200MHz] [1400MHz] [1600MHz] [1800MHz] [2000MHz] [Auto]
HT Link Width [Auto]
Sets the HyperTransport link width. Configuration options: [Auto] [4 Bit] [8 Bit] [16 Bit]
HT Over Voltage [Auto]
Sets the HT over voltage. The values range from 1.25000V to 1.38500V with a 0.01500V
increment. Use the <+> / <-> keys to adjust the value. Configuration options: [Auto] [Max. =
1.38500V] [Min. = 1.25000V]
The following items only appear when you set Ai Overclock Tuner to [Manual].
CPU Bus Frequency [200]
Sets the CPU frequency. Configuration options: [Min.=200] [Max.=550]
PCIE Frequency
Sets the PCIe frequency. Configuration options: [Min.=100] [Max.=150]
The following item only appears when you set Ai Overclock Tuner to [Overclock Profile].
