ASUS M4A89TD PRO
2-3
Chapter 2
2.2.2
Layout contents
Connectors/Jumpers/Slots
Page
1.
ATX power connectors (24-pin EATXPWR, 8-pin EATX12V)
2-33
2.
AM3 CPU Socket
2-5
3.
CPU, chassis, and power fan connectors (4-pin CPU_FAN,
4-pin CHA_FAN1, 3-pin CHA_FAN2, 3-pin PWR_FAN)
2-31
4.
DDR3 DIMM slots
2-10
5.
Core Unlocker switch (CORE_UNLOCKER)
2-22
6.
Turbo Key II switch (TURBO_KEY_II)
2-21
7.
MemOK! switch
2-20
8.
Serial port connector (10-1 pin COM1)
2-29
9.
IDE connector (40-1 pin PRI_EIDE)
2-27
10.
Standby power LED (SB_PWR)
2-36
11.
AMD
®
SB850 Serial ATA 6.0 Gb/s connectors (7-pin SATA1–6)
2-28
12.
System panel connector (20-8 pin PANEL)
2-34
13.
USB connectors (10-1 pin USB910, USB1112, USB1314)
2-30
14.
Digital audio connector (4-1 pin SPDIF_OUT)
2-32
15.
IEEE 1394a port connector (10-1 pin IE1394_2)
2-29
16.
Front panel audio connector (10-1 pin AAFP)
2-32
