ix
M4N72-E specifications summary
(continued on the next page)
CPU Phenom™ X4 / Phenom™ X3 / Athlon™ X2 /
Athlon™ / Sempron™ processors (socket AM2+/AM2)
Compatible with Phenom™ II / Athlon™ X4 /
Athlon™ X3 / Athlon™ X2 (AM3 CPU)
Support 45nm CPU
AMD ® Cool’n’Quiet™ Technology
Chipset NVIDIA ® nForce ® 750a SLI™
System bus Up to 5200 MT/s HyperTransport™ 3.0 interface
for AM3 / AM2+ CPU
2000 / 1600 MT/s for AM2 CPU
Memory 4 x DIMM, max. 16 GB, DDR2 1066* / 800 / 667 MHz,
ECC / non-ECC, un-buffered memory
Dual-channel memory architecture
* Due to AMD ® CPU limitation, DDR2 1066 is supported by
AM3/AM2+ CPUs for one DIMM per channel only.
Refer to www.asus.com for the memory QVL (Qualified
Vendors Lists).
** Due to OS limitation, when installing total memory of
4GB capacity or more, Windows ® 32-bit operation
system may only recognize less than 3GB. Hence, a
total installed memory of less than 3GB is recommended.
Multi-GPU support Supports NVIDIA ® SLI™ Technology at x8 link
Expansion slots 2 x PCIe 2.0 x16 slots (Single x16 or Dual x8)
2 x PCIe x1 slots
2 x PCI 2.2 slots
Storage NVIDIA ® nForce 750a SLI™ chipset
1 x Ultra DMA 133/100
6 x SATA 3 Gb/s ports (Legacy IDE operation is only
supported on drives 1–4)
NVIDIA ® MediaShield™ RAID supports RAID 0, 1, 0+1,
5, and JBOD
LAN Realtek ® 8211CL Gigabit LAN controller featuring AI NET 2
Audio VIA1708S 8-channel High Definition Audio CODEC
- Supports Jack-Detection, Multi-Streaming,
and Front Panel Jack-Retasking
- Optical S/PDIF Out port at back I/O
- ASUS Noise Filtering
IEEE 1394 VIA ® VT6315N controller supports 2 x IEEE 1394a ports
USB 12 x USB 2.0 ports (6 ports at midboard; 6 ports at back
panel)
