Supplied Components
If any component should be missing, please contact your dealer.
 Liquid Crystal Display Monitor: 1
 Power cord: 3
 AC adapter: 1
 Setup Manual: 1
 DisplayPort cable: 1
 RS-232C conversion cable (Φ3.5 mini-jack): 1
 Pedestal (for stand): 1
 Strut (for stand): 1
 Attachment plate (for stand): 1 (preinstalled on monitor)
 Countersunk screws (M4 x 6 without washers): 5
 Screws (M4 x 10 with washers): 4
 Hex wrench: 1
 Cable clamp: 2
 Cable clamp (small): 1
 Cable clamp (large): 2
 Horizontal sticker (Operation buttons): 1
Contents
IMPORTANT INFORMATION ............................................3
DEAR ASUS
® CUSTOMER ...............................................4
SAFETY PRECAUTIONS ..................................................4
TIPS AND SAFETY INSTRUCTIONS ...............................6
MOUNTING PRECAUTIONS ............................................7
Supplied Components .....................................................8
Part Names .......................................................................9
Installing the stand (supplied) ......................................10
Connecting Peripheral Equipment ...............................12
Connection with a PC or AV equipment .....................12
Connecting the Power Cord .........................................13
Binding Cables ...............................................................14
Turning Power On/Off ....................................................15
Turning on the main power.........................................1
Turning power on/off ..................................................1
Basic Operation .............................................................16
Menu Items .....................................................................18
Displaying the menu screen .......................................1
Menu item details .......................................................19
Initialization (Reset)/Functional Restriction Setting
(FUNCTION) ....................................................................22
Controlling the Monitor with a PC (RS-232C) ..............23
PC connection ............................................................2
Communication conditions .........................................2
Communication procedure .........................................2
RS-232C command table ...........................................2
Troubleshooting .............................................................27
Specifications ...............................................................28
