MONITOR menu

Function

Command Direction

Parameter

Reply

Control/Response contents

*

MONITOR

STDR

WR

0-1

0-1 0: LANDSCAPE, 1: PORTRAIT

-

OFF IF NO OPERATION

ATOF

WR

0-1

0-1 0: OFF, 1: ON

-

OTHERS menu

Function

Command Direction

Parameter

Reply

Control/Response contents

*

SCREEN
MOTION

PATTERN

SCSV

WR

0,2,

0,2, 0: OFF, 2: PATTERN1, : PATTERN2

-

MOTION TIME 1

MTIM

WR

0-20

0-20

MOTION TIME 2

MINT

WR

-20

-20 Per second

SIZE

WIDE

WR

1-

1- 1: WIDE, 2: NORMAL, 3: Dot by Dot

-

MUTE AUDIO

MUTE

WR

0-1

0-1 0: OFF, 1: ON

-

INFORMATION MODEL

INF1

R

Value

SERIAL NO

SRNO

R

Value

Initialization/Functional Restriction Setting (FUNCTION) menu

Function

Command Direction

Parameter

Reply

Control/Response contents

*

ALL RESET

RSET

W

0

-

ADJUSTMENT LOCK

ALCK

WR

0-2

0-2 0: OFF, 1:ON 1, 2:ON 2

-

OSD DISPLAY

LOSD

WR

0-2

0-2 0: ON 1, 1: OFF, 2: ON 2

-

LED

OFLD

WR

0-1

0-1 0: ON, 1: OFF

-

TEMPERATURE ALERT

TALT

WR

0-2

0-2 0: OFF, 1: OSD & LED, 2: LED

-

STATUS ALERT

SALT

WR

0-2

0-2 0: OFF, 1: OSD & LED, 2: LED

-

Others

Function

Command Direction

Parameter

Reply

Control/Response contents

*

VOLUME

VOLM

WR

0-1

0-1

-

BRIGHT

VLMP

WR

0-1

0-1

-

TEMPERATURE SENSOR

DSTA

R

0 Internal temperature normal

1 Internal temperature abnormal has occurred and the monitor is in

standby mode

2 Internal temperature abnormal occurred (To delete the information of

temperature abnormal, turn off the main power.)

Internal temperature abnormal has occurred and backlight brightness is

dimmed

Temperature sensor abnormal

TEMPERATURE ACQUISITION

ERRT

R

Value Returns the temperature of the temperature sensor.

Indicates a temperature sensor abnormality when “126” is returned.

-

CAUSE OF LAST STANDBY MODE

STCA

W

0

Initialization

R

0 No detectable error has occurred
1 Standby mode by POWER button
2 Main power off by the main power switch
Standby mode by RS-232C
Input signal waiting mode by No Signal
Standby mode by abnormal temperature

20 Standby mode by OFF IF NO OPERATION setting

Controlling the Monitor with a PC (RS-232C)
