35 ASUS P5GC-VM
Srpski
1. Izgled matične ploče
2. Instalacija procesora
Pratite sledeća uputstva za instalaciju Intel ® LGA 775 procesora.
1. Pritisnite polugu palcem (A), potom je pomerite na levo (B) dok je ne
oslobodite.
Držač
Poluga
Strana okrenuta ka vama
Zaštitni poklopac
A
B B
22.7cm (8.95in)
24.4cm (9.6in
)
DDR2 DIMM_A1 (64 bit,240-pin module) DDR2 DIMM_A2 (64 bit,240-pin module) DDR2 DIMM_B1 (64 bit,240-pin module) DDR2 DIMM_B2 (64 bit,240-pin module)
P5GC-VM
LAN1_USB12
AUDIO
LGA775
Super I/O
Intel ICH7 Intel ICH7
PARALLEL
PO
RT
VGA
COM1
PS/2KBMS
T: Mouse
B: Keyboard
USB34
R
FL
OP
PY
EA
TXPW
R
CPU_FAN
SPDIF_OUT
CD AAFP
SATA4
SATA3
SATA2
SATA1
PRI_IDE 4Mb
BIOS
CLRTC
CHASSIS SPEAKER TPM F_PANEL
CR2032 3V
Lithium Cell
CMOS Power
Intel 82945GC
PCI2
PCI3
PCI1
PCIEX16
USB78 USB56
SB_PWR
CHA_FAN
ALC662
Attansic
L1
ICS 9L PRS412
PS2_USBPW
ATX12V
COM2
F_PANEL
PLED- PWR PLED+
Groun
d
GND
Reset
IDELED+ IDELED-
HD LED RESET
PLED PWRSW
CLRTC
Normal Clear RTC
(Default)
1 2 2 3
3 2 2 1
PS2_USBPW
+5V
(Default)
+5VSB
