ASUS M5A78L-M LX Series 2-11
VDDNB Over Voltage [Auto]
Sets the VDDNB over voltage. The valid value ranges vary depending on your CPU model.
Use <+> / <-> keys to adjust the ratio. Configuration options: [Auto]
LoadLine Calibration [Auto]
Sets the LoadLine. Configuration options: [Auto] [0%] [3.225%] [6.450%] [9.675%] [12.90%] ~
[87.075%] [90.3%] [93.525%] [96.75%] [100%]
If the system becomes unstable after changing the setting, set it back to [Auto] for safe
mode.
HT Link Speed [Auto]
Sets the HyperTransport link speed. Configuration options: [Auto] [200MHz] [400MHz]
[600MHz] [800MHZ] [1000MHz] [1200MHz] [1400MHz] [1600MHz] [1800MHz] [2000MHz]
HT Over Voltage [Auto]
Sets the HT over voltage. The values range from 1.20000V to 1.38000V with a 0.01000V
increment. Use the <+> / <-> keys to adjust the value. Configuration options: [Auto]
[Max. = 1.38000V] [Min. = 1.20000V]
DRAM Timing Config [Auto]
Configuration options: [Auto] [Manual]
DRAM Timing Configuration
The configuration options for some of the following items vary depending on the DIMMs you
install on the motherboard.
DRAM CAS# Latency [Auto]
Configuration options: [Auto] [4 CLK] ~ [12 CLK]
DRAM RAS# to CAS# Delay [Auto]
Configuration options: [Auto] [5 CLK] ~ [12 CLK] [5 CLK] ~ [12 CLK]
DRAM RAS# PRE Time [Auto]
Configuration options: [Auto] [5 CLK] ~ [12 CLK] [5 CLK] ~ [12 CLK]
DRAM RAS# ACT Time [Auto]
Configuration options: [Auto] [15 CLK] ~ [30 CLK] [15 CLK] ~ [30 CLK]
DRAM READ to PRE Time [Auto]
Configuration options: [Auto] [4 CLK] [5 CLK] [6 CLK] [7 CLK] [4 CLK] [5 CLK] [6 CLK] [7 CLK]
DRAM Row Cycle Time [Auto]
Configuration options: [Auto] [12 CLK] ~ [42 CLK]
The following items only appear when you set DRAM Timing Config to [Manual].
Memory Clock Speed [400MHz]
Selects the memory clock frequency programming method.
Configuration options: [400MHz] [533MHz] [667MHz] [800MHz]
