ASUS M4A88T-V EVO Series 2-21
Memory Hole Remapping [Enabled]
Allows you to enable or disable memory remapping around memory hole.
Configuration options: [Disabled] [Enabled]
DCT Unganged Mode [Always]
Allows you to select the unganged DRAM mode (64-bit width).
Configuration options: [Auto] [Always]
Power Down Enable [Disabled]
Allows you to enable or disable DDR power down mode.
Configuration options: [Disabled] [Enabled]
ECC Configuration
ECC Mode [Disabled]
Enables or disables the DRAM ECC that allows the hardware to report and correct
memory errors automatically. Configuration options: [Disabled] [Basic] [Good] [Super]
[Max] [User]
PCIEX16_2/PCIEX1_1 Force [Auto] (for M4A88T-V EVO/USB3 only)
Allows you to manually adjust the PCIe x16_2 / PCIe x1_1 configuration. Configuration
options: [X4 Mode (fast)] [Auto]
Auto
Automatically optimizes performance and functionality according to devices installed.
And when you install a X1 card on the PCIe X1 slot, the PCIe X16_2 slot will run at
X2 speed so that you cannot set up a CrossfireX configuration.
x4 Mode (fast)
Allows you to get the best performance, and the PCIe x1 slot is disabled under this
mode.
• Some PCIe graphics cards cannot operate on x4 / x2 mode. We suggest that you install
these cards on the primary PCIe x16 slot (blue) for better system stability.
• Some PCIe devices cannot operate on x4 / x2 mode.
Internal Graphics
Primary Video Controller [GFX0-GPP-IGFX-PCI]
Allows you to set the primary display adapter. Configuration options: [GFX0-GPP-IGFX-PCI]
[GPP-GFX0-IGFX-PCI] [PCI-GFX0-GPP-IGFX] [IGFX-GFX0-GPP-PCI]
Internal Graphics Mode [UMA+SidePort]
Selects the internal graphics mode. Configuration options: [Disabled] [UMA] [SidePort]
[UMA+SidePort]
UMA Frame Buffer Size [Auto]
This item appears only when you set the Internal Graphics Mode item to
[UMA] or [UMA+SIDEPORT]. Configuration options: [Auto] [32MB] [64MB]
[128MB] [256MB] [512MB]
