Asus A7V600-X - Manual (Page 9)

ix
A7V600-X specifications summary
CPU
Chipset
Front Side Bus (FSB)
Memory
Expansion slots
Storage
Audio
LAN
Special Features
Overclocking
Features
Back Panel I/O
Internal I/O
Connectors
(continued on the next page)
Socket A for AMD Athlon XP/Athlon/Duron with
Thoroughbred/Barton Core support
Northbridge: VIA KT600
Southbridge: VIA VT8237
400/333/266/200Mhz
3 x 184-pin DDR DIMM Sockets support a maximum of 3GB
unbuffered non-ECC PC3200/2700/2100 DDR SDRAM
memory
1 x AGP 8X
6 x PCI
2 x UltraDMA 133/100/66
2 x Serial ATA with RAID 0, RAID 1 and JBOD support
ADI AD1888 6-channel CODEC
S/PDIF out interface
Integrated 10/100 Mbps LAN controller
ASUS EZ Flash
Power Loss Restart
ASUS C.O.P. (CPU Overheating Protection)
ASUS CrashFree BIOS 2
ASUS Instant Music Lite
ASUS JumperFree
ASUS C.P.R. (CPU Parameter Recall)
CPU Voltage adjustable
SFS (Stepless Frequency Selection) from 100Mhz up to
250MHz at 1MHz increment
1 x Parallel
1 x Serial
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x Audio I/O
4 x USB 2.0
1 x RJ-45 Port
1 x S/PDIF out port
CPU/Chassis FAN connectors
20-pin ATX power connector
Chassis Intrusion
GAME/MIDI connector
CD/AUX audio in
Front panel audio connector
2 x USB 2.0 connector supports additional 4 USB 2.0 ports
2 x Serial ATA port
