ASUS Book Size Barebone System 1-3
1.2 Rear Panel Features
The rear panel of the ASUS Book Size Barebone System includes the
standard PC99 I/O connectors for external devices, power supply socket,
and optional feature connectors.
The rear panel features:
Setting the switch to 115V in a 230V environment or 230V in a
115V environment will seriously damage the system!
Voltage Selector
The switching power supply that came with
the system has a voltage selector switch
below the power socket. Use this switch to
select the appropriate voltage according to
the voltage supply in your area.
If the voltage supply in your area is 100-127V,
set the switch to 115V.
If the voltage supply in your area is 200-240V,
set the switch to 230V.
115V/230V
Voltage Selector
PS/2 Mouse
Parallel Port
LAN Port
Power Supply
Serial Port
PS/2 Keyboard
VGA Port
Line Out
Line In
Microphone
USB (0&1)
DVI-Out
S-Video
TV-Out
