1-6 Chapter 1: Product introduction
1.5.3 Motherboard layout
1.5.4 Layout contents
Connectors/Jumpers/Slots Page Connectors/Jumpers/Slots Page
1. Keyboard power (3-pin KBPWR) 1-20 9. Speaker connector (4-pin SPEAKER) 1-26
2. ATX power connectors (24-pin EATXPWR, 4-pin
ATX12V)
1-23 10. Serial ATA connectors (7-pin SATA1-4) 1-24
3. USB device wake-up (3-pin USBPW1-4,
USBPW5-8)
1-20 11. USB connectors (10-1 pin USB56, USB78) 1-27
4. Intel CPU socket 1-7 12. System panel connector (10-1 pin F_PANEL) 1-26
5. CPU and chassis fan connectors
(4-pin CPU_FAN, 3-pin CHA_FAN)
1-22 13. Digital audio connector (4-1 pin SPDIF_OUT) 1-23
6. DDR2 DIMM sockets 1-12 14. Onboard LED 1-4
7. IDE connector (40-1 pin PRI_IDE) 1-25 15. Front panel audio connector (10-1 pin AAFP) 1-27
8. Clear RTC RAM (3-pin CLRTC) 1-19 16. Optical drive audio connector (4-pin CD) 1-24
Contents
2. 1-20
3. 1-20
1. 1-22
2. 1-23
3. 1-23
4. 1-24
5. 1-24
6. 1-25
10. Front panel audio connector (10-1 pin AAFP) 1-27
