ASUS SL100
Configuring Your Computers
This section provides instructions for configuring the Internet settings on
your computers to work with the router.
Before you begin
By default, the ASUS SL100 automatically assigns all required Internet
settings to your PCs. You only need to configure the PCs to accept the
information when it is assigned.
In some cases, you may want to configure network settings
manually to some or all of your computers rather than allow
the Internet Security Router to do so. See Assigning static
IP addresses to your PCs on page 10 for instructions.
If you have connected your PC via Ethernet to the router, follow the
instructions that correspond to the operating system installed on your PC.
Windows ® XP PCs
1. In the Windows task bar, click Start -> Control Panel.
. Double-click the Network Connections icon.
. In the LAN or High-Speed Internet window, right-click on icon
corresponding to your network interface card (NIC) and select Proper-
ties. This icon is often labeled as Local Area Connection
The Local Area Connection dialog box displays with a list of currently
installed network items.
4. Ensure that the check box to the left of the item labeled Internet
Protocol TCP/IP is checked, and click <Properties>.
5. In the Internet Protocol (TCP/IP) Properties dialog box, click the radio
button labeled Obtain an IP address automatically. Also click the radio
button labeled Obtain DNS server address automatically.
. Click <OK> twice to confirm your changes, and close the Control
Panel.
