ASUS SL100
Quick installation
Hardware connection
Before you begin, turn the power off for all devices.
These include your computer(s), your LAN hub/switch (if
applicable), and the ASUS SL100.
Step 1: Connect an ADSL or a cable modem
To connect the router
Connect one end of the Ethernet cable to the port labeled WAN on the
rear panel of the device. Connect the other end to the Ethernet port on the
ADSL or cable modem.
Figure 1. Overview of Hardware Connections
