Asus TS500-E5/RX8 User Manual
Page 37
2-17
ASUS TS500-E5
3. Unscrew and remove the blank tray
from the frame.
4. Place a hard disk drive on the tray
and secure it with four screws.
To install a SATA/SAS hard disk drive:
1. Pull down the tray lever until the
tray pops out slightly, indicating that
it is released.
2. Holding on the tray lever, pull out
the HDD tray from the bay.
