xi
M4A785T-M specifications summary
USB Supports up to 12 USB 2.0/1.1 ports (6 ports at mid-board,
6 ports at the back panel)
LAN Realtek ® 8112L PCIe Gigabit LAN controller
ASUS unique
features
ASUS Q-Fan
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS MyLogo 2
ASUS Express Gate
ASUS AI NET 2
ASUS EPU-4 Engine
ASUS Anti-Surge Protection
ASUS overclocking
features
Intelligent overclocking tool:
– Turbo Key
– GPU NOS
SFS (Stepless Frequency Selection):
– FSB tuning from 200MHz to 550MHz at 1MHz increment
– PCIe frequency tuning from 100MHz to 150MHz at 1MHz
increment
Overclocking Protection:
ASUS C.P.R. (CPU Parameter Recall)
Back panel I/O ports 1 x PS/2 Keyboard port
1 x LAN (RJ-45) port
1 x VGA port
1 x DVI-D port
1 x HDMI port
1 x Optical S/PDIF Out port
6 x USB 2.0/1.1 ports
8-channel audio I/O ports
Internal I/O
connectors
3 x USB 2.0/1.1 connectors support additional
6 USB 2.0/1.1 ports
1 x IDE connector
1 x COM connector
1 x LPT connector
6 x SATA connectors
1 x High definition front panel audio connector
1 x System panel connector
1 x S/PDIF Out connector
1 x CPU fan connector
1 x Chassis fan connector
1 x 24-pin EATX power connector
1 x 4-pin ATX 12V power connector
(continued on the next page)
