ASUS P5E64 WS Professional 2-5
Internal connectors Page
1. Floppy disk drive connector (34-1 pin FLOPPY) 2-26
2. IDE connector (40-1 pin PRI_IDE) 2-27
3. ICH9R Serial ATA connectors [blue] (7-pin SATA1-6) 2-28
4 Marvell ® 88SE6145 Serial ATA RAID connectors [black] (7-pin
EXT_SATA1-2)
2-29
5. USB connectors (10-1 pin USB78, USB910, USB1112) 2-30
6. IEEE 1394a port connector (10-1 pin IE1394_1) 2-30
7. Optical audio drive connector (4-pin CD) 2-31
8. Serial port connector (10-1 pin COM1) 2-31
9. CPU, chassis, and power fan connectors (4-pin CPU_FAN,
3-pin CHA_FAN1-2, 3-pin PWR_FAN)
2-32
10. Chassis intrusion connector (4-1 pin CHASSIS) 2-32
11. Front panel audio connector (10-1 pin AAFP) 2-33
12. TPM connector (20-1 pin TPM) 2-33
13. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V) 2-34
14. System panel connector (20-8 pin PANEL) 2-35
15. ASUS Q-connector (system panel) 2-36
