ASUS ASMB6-iKVM
2-11
2.5
Running the ASMC6 utility
The ASMC6 utility allows you to update the ASMB6-iKVM firmware, configure the
LAN setting for the remote server and change the user name/password in DOS
environment. This utility is available from the support CD that came with the package.
To run the ASMC6 utility:
1. Insert the support CD into the optical drive.
2. Restart the remote server, then press during POST to enter the BIOS
setup.
3. Go to Boot menu and set the Boot Device Priority item to [CD-ROM].
4. When finished, press
5. On reboot, the main menu appears. Select FreeDOS command prompt, and
then press
Press any key to see next page.
6. When the C:> prompt appears, type ASMC6 -?, then press
display the ASMC6 Utility Help Menu. The screen appears as shown.
ASUS Server Z9PE-D16 MB
FreeDOS command prompt
Configure BMC IP Source Static IP for LAN1
Configure BMC IP Source DHCP for LAN1
Configure BMC IP Source Static IP for DM_LAN1
Configure BMC IP Source DHCP for DM_LAN1
ASMB6 Firmware Update for Preserve Configuration (SDR,LAN,Username)
ASMB6 Firmware Update for Clear Configuration (SDR,LAN,Username)
+----------------------------------------------------------+
| ASUS Server Management Card Utility 6.01 Help Menu |
+----------------------------------------------------------+
Usage:
ASMC6 -kcs[smic/bt/pci_smic] NetFn command data....
ASMC6 -bmc_ip_source source[1:Static, 2:DHCP]
ASMC6 -bmc_ip ip_addr[10.10.10.20]
ASMC6 -bmc_mask ip_mask[255.255.255.0]
ASMC6 -bmc_gateway ip_addr[10.10.10.254]
ASMC6 -pet_ip_mac ip_addr[10.10.10.20] mac_addr[010203040506]
ASMC6 -bmc_ip_s_lan1 source[1:Static, 2:DHCP]
ASMC6 -bmc_ip_lan1 ip_addr[10.10.10.20]
ASMC6 -bmc_mask_lan1 ip_mask[255.255.255.0]
ASMC6 -bmc_g_lan1 ip_addr[10.10.10.254]
ASMC6 -pet_ip_m_lan1 ip_addr[10.10.10.20] mac_addr[010203040506]
ASMC6 -adm_name new_name_string
ASMC6 -user_name new_name_string
ASMC6 -adm_password new_adm_password
ASMC6 -user_password new_user_password
