viii
P8H77-V LE specifications summary
(continued on the next page)
CPU LGA1155 socket for Intel ® 3rd/2nd Generation Core™ i7/ i5/ i3/
Pentium ® / Celeron ® Processors
Supports 22nm and 32nm CPU
Supports Intel ® Turbo Boost Technology 2.0*
*The Turbo Boost Thchnology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel ® CPU support list.
Chipset Intel ® H77 Express Chipset
Memory 4 x DIMM, maximum 32GB, DDR3 1866(O.C.)*/1600/1333/1066 MHz,
non-ECC, un-buffered memory
Dual-channel memory architecture
Supports Intel ® Extreme Memory Profile (XMP)
* Due to the CPU behavior, DDR3 1866 MHz memory module will run
at DDR3 1800 MHz frequency as default.
** Hyper DIMM support is subject to the physical characteristics of
individual CPUs. Some hyper DIMMs only support one DIMM per
channel. Please refer to Memory QVL for details.
*** Refer to www.asus.com or this User Manual for the Memory
QVL(Qualified Vendors List).
**** When you install a total memory of 4GB capacity or more,
Windows ® 32-bit operating system may only recognize less than
3GB. We recommend a maximum of 3GB system memory if you are
using a Windows ® 32-bit operating system.
Expansion slots 1 x PCI Express 3.0/2.0 x16 slot [bue] (at x16 mode)*
1 x PCI Express 2.0 x16 slot [black] (at x4 mode, compatible with PCIe
x1, x2 and x4 devices)
2 x PCI Express 2.0 x1 slot
3 x PCI slots
* PCIe 3.0 speed is supported by Intel ® 3rd generation Core™
processors.
Graphics Integrated graphics processor - Intel ® HD Graphics support
Multi-VGA output support: HDMI, DVI and RGB port
- Supports HDMI with max. resolution up to 1920 x 1200 @60Hz
- Supports DVI with max. resolution up to 1920 x 1200 @60Hz
- Supports RGB with max. resolution 2048 x 1536@75Hz
- Supports Intel ® InTru™ 3D/Insider™/Quick Sync Video/Clear Video
HD Technology/HD Graphics
- Maximum shared Memory of 1696 MB
Multi-GPU
support
Supports ATI ® Quad-GPU CrossFireX™ Technology
Storage Intel ® H77 Express Chipset:
- 2 x Serial ATA 6.0 Gb/s connectors (gray)
- 4 x Serial ATA 3.0 Gb/s connectors (blue)
- Intel Rapid Storage Technology supports RAID 0, 1, 5 and 10
- Supports Intel ® Smart Response Technology, Intel ® Rapid Start
Technology, Intel ® Smart Connect Technology*
* Supports on Intel ® Core™ processor family with Windows ® 7
operating systems.
